Three Phase Power Distribution Transformers

Name: Three Phase Power Distribution Transformers
Brand: H.D. TRANSFORMERS
Price: 850000 INR
Availability: InStock

Price 850000 INR/ Piece

Get a Price/Quote

MOQ : 10 Pieces

Three Phase Power Distribution Transformers Specification

Voltage Booster Type
Other

Rated Voltage
11 kV / 22 kV / 33 kV

Coil Material
Electrolytic Copper

Standard
IS 1180 / IEC 60076

Cooling Type
ONAN (Oil Natural Air Natural)

Operating Temperature
-25C to +50C

Capacity
Various options (100 kVA to 5000 kVA)

Low Voltage
415 V / 433 V / 690 V

High Voltage
11 kV / 22 kV / 33 kV

Dimension (L*W*H)
Varies with capacity (Typical: 1800 mm x 1100 mm x 1600 mm)

Load Loss
As per IS 1180 / IEC 60076 standards

Product Type
Distribution Transformer

Material
Cold Rolled Grain Oriented (CRGO) Silicon Steel

Output
High Voltage Transmission

Frequency (MHz)
50 Hz

Efficiency
98%

Phase
Three Phase

Usage
Power Distribution

Coil Structure
Laminated

Coil Number
Two Winding

Power Scope
Up to 5000 kVA

Weight
Approx. 1200 kg to 3500 kg (Varies by capacity)

Type of Tank
Corrugated or Plain Tank

Painting
Epoxy Powder Coated (Corrosion Resistant)

Tap Changer
On-Load / Off-Load Tap Changer

Insulation Level
Class A or Class F

Humidity Resistance
Up to 95% RH

Terminal Arrangement
Cable Box / Busbar / Bushing

Protection
Buchholz Relay, Temperature Gauge, Oil Level Indicator

Altitude
Up to 1000 m above sea level

Winding Type
Foil or Spiral Winding

Service Life
25 Years (Typical)

Maximum Temperature Rise
40C above ambient

Impedance Voltage
As per IS/IEC norms

Noise Level
< 60 dB

Polarity
Dyn11 / Yyn0 / Other as required

Cooling Medium
Mineral Transformer Oil

Three Phase Power Distribution Transformers About

Experience the superlative performance of our Three Phase Power Distribution Transformers, designed with special attention to every detail for hot-selling reliability at an unbeatable price. Each unit boasts heroic efficiency up to 98%, featuring insulation levels of Class A or F, and a robust CRGO Silicon Steel core. The perfect transformer for versatile applications, it supports tap changers, advanced protection, low noise, and is corrosion-resistant. With capacities up to 5000 kVA, these transformers deliver sustained high voltage output, enduring up to 25 years-even in challenging Indian conditions. Choose from various winding types, tanks, and terminal arrangements for a tailored solution.

Versatile Applications & Enhanced Features

Three Phase Power Distribution Transformers excel across utility substations, industrial complexes, commercial buildings, and rural electrification sites. They incorporate extra features such as Buchholz relay protection, on-load or off-load tap changers, temperature monitoring, and epoxy powder-coated tanks for ultimate corrosion resistance. Suitable for both indoor and outdoor installations, these transformers perform optimally across varied surfaces and application requirements, ensuring dependable power distribution even in high humidity or elevated terrains up to 1000 meters above sea level.

Sample Availability, Domestic Market, and Secure Delivery

We offer product samples upon request, supporting customers in both domestic and international markets. Our secure shipping process guarantees safe transformer delivery, whether you're serving the domestic mar or exporting globally. Efficient logistics ensure a standard delivery time, and our team provides thorough guidance on installation and commissioning. Charges may apply for sample requests, and we always prioritize transparent communication and customer satisfaction from inquiry stage through to after-sales support.

Cooling Type	Oil Cooled
Phase	3 Phase
Energy Efficiency Level	100
Mounting Type	H
Insulation Class	H
AMC Available	Yes
Country of Origin	Made in India
Power	1500 kVA
Material	Aluminium

FAQ's of Three Phase Power Distribution Transformers:

Q: How can I customize the Three Phase Distribution Transformer for my specific site requirements?

A: You can select various features such as insulation level (Class A or F), tank type (corrugated or plain), winding type (foil or spiral), tap changer options, and terminal arrangements to closely match your site needs and local regulations.

Q: What are the main benefits of choosing this transformer for power distribution?

A: The key benefits include high energy efficiency (up to 98%), long service life (up to 25 years), advanced protection features like Buchholz relay and temperature gauge, corrosion resistance, and flexible installation/operation over a wide range of conditions.

Q: Where are these transformers most commonly used?

A: These transformers are widely used in industrial plants, commercial centers, public utility grids, and rural electrification projects due to their adaptability, robust construction, and ability to withstand harsh environments including high humidity and fluctuating temperatures.

Q: What is the process for obtaining a sample, and are there any associated charges?

A: Samples of our Three Phase Power Distribution Transformers are available upon request, and there may be a nominal charge for samples. Please contact our sales team for details about sample processing and delivery timelines.

Q: How is shipping managed to ensure secure delivery within India or abroad?

A: We utilize secure packaging and reliable logistics partners to guarantee safe transportation and delivery, whether your order is shipped within India or exported to an international destination. Tracking and regular updates are also provided throughout the delivery process.

Q: What extra protection and monitoring features do these transformers include?

A: Each unit includes advanced safety and monitoring tools such as a Buchholz relay for fault protection, temperature gauges, oil level indicators, and noise reduction to ensure safer operation and easier maintenance.
